| 1. Height (center, headrest in lowest position) |
1030mm |
Headrest/Seat Arms/Safety Belt/Seat lumbar Airbag Adjustment Device/Seat cushions and backrests electric heating device (power supply 24V/12V DC) |
| 2.Cushion Width |
490mm |
| 3. Backrest Width |
480mm |
| 4. Surface Height(center) |
310mm |
| 5. SIP Point(center) |
To the Front 330mm To the Bottom 340mm |
| 6. Headrest Adjustment Range (Height) |
75mm |
| 7. Backrest Adjustable Angle |
Front 60°、Back 25° |
| 8. Front to Back Adjustable Distance |
175mm |
| 9. Height adjustment Distance |
60mm |
| 10. Skin Material |
PVC synthetic leather or fabric |
| 11. Installing Hole Size |
215*280*4-φ9 |
| 12.. Surface Angle Range |
±12° |
| 13. Shock Damping Mode |
Air bag damping(compressed air connection) |
| 14. Front to back of lumbar airbag adjustment |
compressed air connection |
| 15. Damping Device Stroke |
60mm |
| 16. Weight Adjustable Range |
50kg-130kg |
| 17. Cushions and backrests electric heating |
Power supply 24V/12V DC |
| 18. Fixed-base damping can lock |
|
