| 1. Height (center, headrest in lowest position) |
1200mm |
Headrest/Seat Arms/Safety Belt/Seat Lumbar Mechanical Adjustment Device |
| 2.Cushion Width |
500mm |
| 3. Backrest Width |
500mm |
| 4. Surface Height(center) |
400mm |
| 5. SIP Point(center) |
To the Front 360mm To the Bottom 430mm |
| 6. Headrest Adjustment Range (Angle、Height) |
80°、75mm |
| 7. Backrest Adjustable Angle |
Front 80°、Back 50° |
| 8. Front to Back Adjustable Distance of Seat cushion and backrest |
175mm |
| 9. Front to Back Adjustment Distance of Seat |
175mm |
| 10. Height adjustment Distance |
60mm |
| 11. Skin Material |
PVC synthetic leather, genuine leather or fabric |
| 12. Installing Hole Size |
280*280*4-φ9 |
| 13. Arms are adjustable (luxury) |
|
| 14.. Surface Angle Range |
±12° |
| 15. Shock Damping Mode |
Mechanical Damping |
| 16. Damping Device Stroke |
60mm |
| 17. Weight Adjustable Range |
50kg-130kg |
| 18. Seat lumbar |
totally 3 gears mechanical adjustment front and back |
